ASRock H810M-X WiFi Intel H810 LGA1851 DDR5 Micro-ATX 2.5GbE Motherboard

Description

The ASRock H810M-X WiFi is a compact Micro-ATX computer motherboard built around the Intel H810 chipset and LGA1851 socket for Intel Core Ultra processors (Series 2). It combines a practical layout with dual-channel DDR5 support, making it suitable for efficient office, home and general-purpose PC builds where modern connectivity and a smaller board footprint are important.

Two DDR5 DIMM slots support up to 128GB of system memory and speeds up to 6400 MT/s. Expansion is handled by one PCIe 4.0 x16 slot plus one PCIe 4.0 x1 slot. Storage options include one Hyper M.2 socket running at PCIe Gen4x4 and four SATA III connectors, giving this micro ATX motherboard a useful mix of fast NVMe storage and conventional SATA expansion.

For networking, the board provides Realtek 2.5 Gigabit Ethernet together with dual-band 802.11ac Wi-Fi and Bluetooth 5.0. Display connectivity includes HDMI 2.1, DisplayPort 1.4 and D-Sub for processors with integrated graphics. USB connectivity includes rear and front USB 3.2 Gen1 ports, a front USB Type-C header and USB 2.0. Realtek ALC897 7.1-channel HD audio, RGB and addressable RGB headers, AMI UEFI BIOS and a 24-pin ATX plus 8-pin CPU power design complete this well-equipped PC motherboard.

Brand ASRock
Model H810M-X WiFi
MPN 90-MXBS6-A0UAYZ
Socket LGA 1851
Chipset Intel H810
Supported Processors Intel Core Ultra Series 2
Form Factor Micro-ATX
Memory Technology DDR5
Memory Slots 2 × DIMM
Maximum Memory 128GB
Memory Speed Up to 6400 MT/s
PCIe x16 Slots 1 × PCIe x16 (PCIe 4.0 x16)
Additional PCIe Slots 1 × PCIe 4.0 x1
M.2 Slots 1 × Hyper M.2 (PCIe Gen4x4)
SATA Ports 4 × SATA III
Wireless Connectivity Wi-Fi 5, Bluetooth 5.0
LAN 2.5 Gigabit Ethernet
Video Outputs HDMI, DisplayPort, D-Sub
USB USB Type-A, USB Type-C
Audio 7.1 Channel HD Audio (Realtek ALC897)
BIOS 256Mb AMI UEFI
Internal Headers RGB, 2 × Addressable RGB, TPM, USB 2.0, USB 3.2 Gen1, front USB-C
Power Connectors 24-pin ATX, 8-pin 12V
Rear I/O PS/2, D-Sub, HDMI, DisplayPort, 2 × USB 3.2 Gen1, 4 × USB 2.0, RJ-45, audio jacks, antenna ports
Operating System Windows 11 64-bit
Product form

Barcode: 4711581490659

ASRock H810M-X WiFi Intel H810 LGA1851 DDR5 Micro-ATX 2.5GbE Motherboard

The ASRock H810M-X WiFi is a compact Micro-ATX computer motherboard built around the Intel H810 chipset and LGA1851 socket for... Read more

3 in stock Next day delivery

£110.00  £100.00 Incl. VAT

    • Guaranteed secure & safe checkout.

      klarna
    • Free shipping on all orders above £ 100
    • No hassle returns, 14 days return
    Pay whenever you want

    Easily pay within 30 days after you have received your package.
    Read more

    Description

    The ASRock H810M-X WiFi is a compact Micro-ATX computer motherboard built around the Intel H810 chipset and LGA1851 socket for Intel Core Ultra processors (Series 2). It combines a practical layout with dual-channel DDR5 support, making it suitable for efficient office, home and general-purpose PC builds where modern connectivity and a smaller board footprint are important.

    Two DDR5 DIMM slots support up to 128GB of system memory and speeds up to 6400 MT/s. Expansion is handled by one PCIe 4.0 x16 slot plus one PCIe 4.0 x1 slot. Storage options include one Hyper M.2 socket running at PCIe Gen4x4 and four SATA III connectors, giving this micro ATX motherboard a useful mix of fast NVMe storage and conventional SATA expansion.

    For networking, the board provides Realtek 2.5 Gigabit Ethernet together with dual-band 802.11ac Wi-Fi and Bluetooth 5.0. Display connectivity includes HDMI 2.1, DisplayPort 1.4 and D-Sub for processors with integrated graphics. USB connectivity includes rear and front USB 3.2 Gen1 ports, a front USB Type-C header and USB 2.0. Realtek ALC897 7.1-channel HD audio, RGB and addressable RGB headers, AMI UEFI BIOS and a 24-pin ATX plus 8-pin CPU power design complete this well-equipped PC motherboard.

    Brand ASRock
    Model H810M-X WiFi
    MPN 90-MXBS6-A0UAYZ
    Socket LGA 1851
    Chipset Intel H810
    Supported Processors Intel Core Ultra Series 2
    Form Factor Micro-ATX
    Memory Technology DDR5
    Memory Slots 2 × DIMM
    Maximum Memory 128GB
    Memory Speed Up to 6400 MT/s
    PCIe x16 Slots 1 × PCIe x16 (PCIe 4.0 x16)
    Additional PCIe Slots 1 × PCIe 4.0 x1
    M.2 Slots 1 × Hyper M.2 (PCIe Gen4x4)
    SATA Ports 4 × SATA III
    Wireless Connectivity Wi-Fi 5, Bluetooth 5.0
    LAN 2.5 Gigabit Ethernet
    Video Outputs HDMI, DisplayPort, D-Sub
    USB USB Type-A, USB Type-C
    Audio 7.1 Channel HD Audio (Realtek ALC897)
    BIOS 256Mb AMI UEFI
    Internal Headers RGB, 2 × Addressable RGB, TPM, USB 2.0, USB 3.2 Gen1, front USB-C
    Power Connectors 24-pin ATX, 8-pin 12V
    Rear I/O PS/2, D-Sub, HDMI, DisplayPort, 2 × USB 3.2 Gen1, 4 × USB 2.0, RJ-45, audio jacks, antenna ports
    Operating System Windows 11 64-bit
