Power suply

The Seasonic PRIME Ultra 1000 Gold is a 1000W computer power supply for high-output desktop systems and workstations. This ATX power supply uses a fully modular cable design, so only the required leads need to be installed. Its 80 PLUS Gold efficiency rating is combined with Seasonic’s Micro Tolerance Load Regulation, while the single +12V rail is rated at 83A / 996W.Connectivity includes one 20+4-pin ATX motherboard connector, two 4+4-pin EPS/CPU connectors, eight 6+2-pin PCIe connectors, twelve SATA power connectors, five 4-pin peripheral connectors and one floppy connector. This modular PC power supply follows the ATX12V 2.4 specification. It has no native 12VHPWR or 12V-2x6 connector, so GPUs using those interfaces require a suitable adapter or cable solution.Cooling is handled by a 135mm fluid dynamic bearing fan with selectable Premium Hybrid Fan Control for semi-passive operation. Active PFC supports 100–240V AC input, with OCP, OVP, UVP, OPP, SCP and OTP protection. The unit measures 150 × 86 × 170 mm and is specified for operation up to 50°C. Japanese 105°C capacitors, low-ripple design and a 12-year manufacturer warranty complete this fully modular PC power supply 1000W platform. Brand Seasonic Model PRIME Ultra 1000 Gold MPN SSR-1000GD Rated Power 1000W Form Factor ATX ATX Specification ATX12V 2.4 Efficiency Certification 80 PLUS Gold Modularity Fully Modular +12V Configuration Single +12V Rail +12V Output 83A / 996W Main Connector 1 × 20+4-pin ATX CPU / EPS Connectors 2 × 4+4-pin EPS PCIe Connectors 8 × 6+2-pin PCIe Native 12VHPWR / 12V-2x6 None SATA Connectors 12 Peripheral Connectors 5 × 4-pin Molex Floppy Connector 1 Fan 135mm Fluid Dynamic Bearing Fan Mode Premium Hybrid Fan Control / Semi-Passive Active PFC Yes Protections OCP, OVP, UVP, OPP, SCP, OTP Input Voltage 100–240V AC, 50–60Hz Operating Temperature 0–50°C MTBF 150,000 hours Dimensions 150 × 86 × 170 mm Warranty 12-Year Manufacturer Warranty
